표면 온도 측정센서 Sensors for measuring the surface temperature 모델명: DLE124
► Robust sensor for outdoor applications even in severe environmental conditions
► 4-wires Pt100 technology for long distance cable connections
► Ideal to be attached to the walls for wall surface temperature measurments in building assesments (U fac-tor applications)
► Pt100 1/3 DIN B Class AA sensitive element for outstanding accuracy. (0,15°C)
► Flat cable for cabling in norrow path (EST124)
► Accessories for 4 ÷ 20 mA and RS-485 signal output
► In-house ISO17025 accreditated calibration laboratory
※ For industry and laboratory application only
제품 카달로그
제품문의
Plate sensor for surface temperature measurements. The compact dimensions allow installation even in small spaces. It can be fixed using silicone, double-sided tape or thermo-conductive paste.
