유리 투과 온도측정용 Pyrometer 모델명: MB39
► Measured value acquisition / response time: 3 ms
► Available temperature ranges : 150 – 1000°C
500 – 2500°C
► Spectral range: 3.95 µm
► Smallest spot size: 0.7 mm
Special Applications
At a wavelength of 3.95 µm hot furnace gases and clean burning gas flames are quite transparent and therefore permit temperatures
of substances to be measured as well during the heating up process in industrial furnaces when using the Metis MB39 series.
The Metis MB39 uses this narrow range, so that metal parts or glass ceramics can be measured through flames and combustion gases.
Further the device is used for measurement of glass. In difference to conventional glass devices that measure glass surfaces at 5.14 µm,
with 3.95 µm a slightly intruding measurement into glass is possible (e.g. for glass drop measurements).
