유량 계산시스템 Flow Calculation System 모델명: Flow Calculation System
제품 카달로그
견적문의
Technical data: |
||
4 differentioal pressure sondes: |
accuracy of terminal value 0,4% |
|
Measuring ranges: |
25 Pa, 100 Pa, 400 Pa, 2500 Pa |
|
Barometic pressure sensor: |
0,5% accuracy from the final value |
|
Measuring range: |
800 - 1100 mbar |
|
Rel. humidity: |
2,5% r.h. humidity |
|
Measuring range: |
5% to 98% |
|
Temperature probe: |
0,2% accuracy |
|
Measuring range: |
-40°C to +60°C, PT 100, Class A |
|
Datacard: |
National Instrument NI USB 6211 |
|
Cutting point: |
USB |
|
Disbanding: |
16 bit |
|
Samplerate: |
250 kS/s |
|
Feed-in: |
230 V / 50 Hz |
|
Dimensions (width, height, length): |
364 x 150 x 391 mm |
