Universal signal connections
♦ Direct connection of all typical signals and sensors in electromechanical testing
♦ Integrated signal conditioning, anti-aliasing filter and optional sensor supply
♦ Supports automatic sensor recognition (TEDS)
♦ Precise digitization and locally occurring evaluations and preprocessing
The appropriate housing for every application
♦ Five different designs for every application: From measurements in the engine compartment at 120°C to permanent installations on test stands
♦ Wide temperature range of -40/-30°C (type permitting) to + 85°C with allowed condensation; versions available for even the most extreme temperatures of -40C to +120C
♦ Compact module design allows for near-sensor placement and reduces potential electrical interference
Simple configuration
♦ Confi gurable via imc STUDIO, imc CANSAS or CANOpen
♦ Direct access to all relevant CAN parameters (baud rate, ID type, message ID, etc.)
♦ Confi guration of real-time calculations in the module and output as virtual channels
♦ Confi guration is saved onboard and loaded when the module is switched on
Simple integration
♦ Fully supports CAN specifi cation (ISO 11898)
♦ Extensive confi guration options for user-specific CAN settings
♦ Extensive heartbeat function for unattended operation in CAN networks
♦ Import and export of module confi gurations using the industry standard DBC
Always synchronously measured
♦ CAN-based synchronization for sample-exact measurements across module boundaries
♦ Synchronization requires no additional cables
