Transducer 모델명: 7723-1
▶ for testing of torque wrenches and torque screwdrivers
▶ processing and digitisation occurs directly in the transducer, ensuring a high level of accuracy
▶ not affected by transverse forces due to its particularly low-profile design
▶ for use with calibration systems or 7707 W workshop testing device
▶ with factory certificate
▶ patented
▶ delivered in a sturdy plastic box
▶ max. accuracy ± 1% of the measured value
제품 카달로그
견적문의
| Product no. | Model | Model No. | Area of application | Accuracy +- 1% of the measured value N·m | Accuracy +- 1% of the measured value ft-lb | Accuracy +- 1% of the measured value in-lb | MA N·m | Nominal value N·m | d | Internal square [inch] | Weight (g) | Weight with box | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 96521023 | 7723-1 | 7723-1 | Drehmomentschlüssel | 4-200 | 3-148 | 35-1770 | 4 N·m | 200 N·m | 120 mm | 1/2 " | 2983 g | 3605 g |
