고주파 Transconductance 증폭기 High Frequency Transconductance Amplifie 모델명: TA1200
► Current output range：1 mA to 10.5 A
► Frequency：DC & 10 Hz to 1 MHz
► Short-term stability：0.004%/min @ DC，0.05%/min @ 100 kHz，0.1%/min @ 1 MHz
► Operation mode: constant current (CC) and transconductance (TA)
► Input voltage at TA mode: 0.2 V to 2 V
► Maximum load voltage: 7 Vrms
※ For industry and laboratory application only
제품 카달로그
제품문의
TA1200 is a high-precision, high-stability broadband constant current source with a frequency of up to 1 MHz and a linear output of current in a transconducting mode of operation, suitable for calibrating the frequency response bandwidth characteristics of high frequency current transducers or testing current transducers.
