► Accuracy: 0.05 % / 0.1 %
► The drift after zero adjustment is very small, the typical value of Class 0.05 is lower than 0.5 μWb/min
► Optional units: Wb, Vs, Wb·cm, Vs·cm, etc.
※ For industry and laboratory application only
TY3100 is a high-precision magnetic moment measuring tester designed with a high-speed microprocessor and a low-drift electronic integrator.
It can be paired with various specifications of magnetic moment measurement coils to measure the magnetic moment M and magnetic flux Φ of magnetic components such as permanent magnet ferrite, AlNiCo, NdFeB, and Samarium Cobalt (SmCo) Magnets. It provides a good test for analyzing and evaluating the magnetizing performance of permanent magnets.
Reference Standard IEC 60404-14:2002 "Methods of measurement of the magnetic dipole moment of a ferromagnetic material specimen by the withdrawal or rotation method".
